Hartland CFX Black Nickel 1 Gang 200VA Inductive Leading Edge Dimmer

78C1X2V

(No reviews yet) Write a Review

Estimating Shipping

RRP: £141.02
£77.57
— You save £63.45
Frequently bought together:

Description

The Hartland CFX Black Nickel 1 Gang 200VA Inductive Leading Edge Push On-Off Rotary 2 Way Switching Dimmer is designed to offer reliable control for low voltage toroidal transformers and some LED lamps. Perfect for use in residential and commercial settings, this high-performance dimmer allows for smooth and efficient dimming of inductive loads. It features a sleek black nickel metal finish, adding a modern touch to any space.

Key Features:

  • Design & Finish: Stylish black nickel plate with a sleek, modern metal finish.
  • Performance: Rated for 1 gang with a maximum load of 200VA (low voltage), ideal for use with toroidal transformers.
  • LED Compatibility: De-rated by 75% for use with dimmable LED lamps (please consult Technical for compatibility).
  • Safety Features: CE Marked and compliant with BS EN 60669-1 standards, ensuring safety and reliability.
  • Ease of Installation: Suitable for internal use only, with a recommended wall box depth of 35mm.
  • Temperature Range: Operates within an ambient temperature range of -5°C to +40°C for consistent performance.

This dimmer is a perfect solution for controlling low voltage lighting, adding functionality and elegance to your electrical setup.

Family Code:
S HART CFX
Product Code:
S HT-C BK
Plate Size:
Single
Minimum Wall Box Depth:
35mm
Insert Colour:
Black Nickel
Plate Material:
Metal
Plate Finish:
Black Nickel
Technical Insert Description:
1 gang 200VA Inductive Leading Edge Push On/Off Rotary 2 Way Switching Dimmer
Current Rating (A):
0.8
CE Marked:
Yes
Wattage (W):
200va (lo voltage)
Max Load:
200VA (low voltage) Min Load 25VA
Voltage (V):
220-240
Switched Poles:
Single
Contact Gap Minimum (mm):
None
Terminal Capacity 1 (mm²):
2x1
Terminal Capacity 2 (mm²):
2x1.5
Earth Terminal Capacity 1 (mm²):
5x1
Earth Terminal Capacity 2 (mm²):
4x1.5
Earth Terminal Capacity 3 (mm²):
3x2.5
Earth Terminal Capacity 4 (mm²):
1x4 Multi-strand
Earth Terminal Capacity 5 (mm²):
1x6
Product Class 1:
Face plate must be earthed
Ambient Operating Temperature:
-5° to +40°C
Recommended Location:
Internal Use Only
Max Installation Altitude:
2000m
BS EN ISO Standard:
BS EN 60669-1
Range:
Hartland CFX
Patents:
CFX is a Registered Trade Mark No 2398667Hartland CFX is a Registered Design under Reference Nos.R21 = 3023446 SS2 =3023445
IP Rating:
IP2XD
Mains Frequency:
50Hz
